Automatic Pay-off Stand Machine Automatic Horizontal Pay-off Flat-Discharge Pay-off Machine Wire Prefeeder Machine Feeder Tool

Basic Info

Model NO.	SR-400
Voltage	220V
Warranty	1 Year
After-sales Service	1 Year
Function	Cable Feeder
Max Load	25kg
Trademark	sinrad
Origin	China

Product Description

Automatic pay-off stand machine Automatic horizontal pay-off Flat-discharge pay-off machine Wire prefeeder machine

SR-300 automatic wire feeding machine adopts Taiwan Shilin inverter to control the speed, Siemens controller controls the start and stop, keep the wire traction tension constant through the pulley group, and meet the needs of long-distance wire feeding to ensure that the entire cable is in the process of the transmission Uniform speed, soothing, guarantee the precision of wire stripping machine.

This machine is suitable for: wire, casing, braided tape, iron wire, copper wire, cable, cloth tape, rope, nylon wire, steel cable, PVC sheet, PVC tape and other tape and coil conveying and delivery lines.

Product Specification

Model	SR-300 single motor	SR-300A dual motor	SR-302 Biaxial	SR-400 heavy load
Size	550x500x750mm	500x900x920mm	700x810x960mm	1700x1400x150mm
Maximum load	25KG	50KG	50KG	200KG
Wattage	120W	240W	240W	1.5KW
Voltage	AC220V 50/60HZ	AC220V 50/60HZ	AC220V 50/60HZ	AC220V 50/60HZ
Weight	38KG	50KG	60KG	180KG

Features

SR-300 automatic wire feeding machine

(1)This machine is an automatic wire feeding machine, which is used in conjunction with a fully automatic computer wire stripping machine, eliminating the need for manual threading. You only need to fix the whole coil of wire on the pay-off rack, start the motor when the wire needs to be fed, and it will automatically stop when the wire is slack to a certain degree.

(2)This machine is compact in design and convenient in setting and clamping the spool, which can greatly reduce labor intensity and improve production efficiency.

(3)It can be used with any type of automatic terminal crimping machine or computer wire cutting machine.

(4)It can be modified and customized according to the special requirements of customers. General cable feeding speed:1.2m/s
